Ultradry-
Drying Range Machine
contact us
Description
Drying of fabric at high steam pressure.
Belt drive for cylinder.
Inverter drive for perfect synchronisation of cylinder dryer.
2 Bowl or 3 Bowl Mangle to be attached with cylinder dryer.
Any fabric of 70 GSM to 450 GSM can be successfully dried.
Indirect drying using stainless steel cylinders.
Suitable for one or two sided drying of all type of fabrics.
High efficiency method for intermediate or final drying.
Optional Accessories
Teflon coating on drying cylinders.
Technical Details
Cylinder width
1200 to 3600 mm
No of cylinders per stack
2 to maximum 20
Cylinder diameter
762 or 800 mm
Drive
Belt drive individual or Alternate motor drive
Speed
10 to 120 meters / min
Frames (Stacks)
In Mild Steel & I Beam Structure
